TE 640 3D Energy
with permanent energy transfer for unrebated high performance heavy-duty doors
* Figures and finishes similar
TE 640 3D Energy
with permanent energy transfer for unrebated high performance heavy-duty doors
Product features
Technical details
Load capacity
200.0 kg
Overall length
240.0 mm
Width (door part)
32.0 mm
Width (frame part)
32.0 mm
Cutter diameter
24.0 mm
Collar ring diameter
30.0 mm
Wire cross section
0.14 mm²
Max. voltage
50 V
No. of wires
16
Max. current
0.8 A
Opening angle
180°
Suitable for
Type of door leaf
timber, metal
Rebate
unrebated
Type of frame
aluminium frame, blind frame, block frame, casing frame, steel frame
Function range
- Smoke resistance
- Soundproof
- Burglar resistance
Note
Descriptive text
Quality marks
CE certification
IFT certification
UL certification
Certifire certificationClassification code
EN 1935 / EAD4
7
6
1 *1
1
— *2
1
14
*1 Test evidence for functional doors to be achieved with full door sets and assemblies.
*2 depending on the finish
Item versions
Satin Chrome Look (F1) (SW 124)
Stainless Steel Look (SSL) (SW 126)
