VARIANT VX
Product image
VX 7939/160 FD Planum
for rebated soundproof doors with acoustic seal, with reduced, elegant knuckle
* Figures and finishes similar
VX 7939/160 FD Planum
for rebated soundproof doors with acoustic seal, with reduced, elegant knuckle
Product features
Technical details
Load capacity
160.0 kg
Knuckle length
160.0 mm
Knuckle diameter
15.0 mm
Cutter diameter
24.0 mm
Collar ring diameter
30.0 mm
Material thickness
3.0 mm
Screws
5.0 x 50.0 mm
Suitable for
Type of door leaf
timber
Rebate
rebated
Type of frame
aluminium frame, blind frame, block frame, casing frame, steel frame
Function range
- Fire resistance
- Smoke resistance
- Soundproof
Note
Descriptive text
Quality marks
CE certification
IFT certification
UKCA certificationClassification code
EN 1935 / EAD4
7
5
1 *1
1
— *2
1
12 *3
*1 Test evidence for functional doors to be achieved with full door sets and assemblies.
*2 depending on the finish
*3 test cycles in continuous operation with 160 kg
Item versions
Satin Stainless Steel (SW 040)
